6.7.7 XG3, mains choke temperature contact
View Connection Function
1 Temperature contact
2
Tab. 6-84: Pin assignment
Mechanical data
Spring terminal (connector) Unit max.
Connection cable
Stranded wire
mm
2
1.5
AWG 16
Stripped length mm 10
Tab. 6-85: Mechanical data
Electrical data
Screw terminal (connector) Unit Value
Nominal current A 8
Nominal voltage V 150
Tab. 6-86: Electrical data
Cables
Description Value
Order type RKH0801
Maximum allowed length 1 m
Tab. 6-87: Cables
IndraDrive Mi Drive Systems with KCU02, KSM02,
KMS02/03, KMV03, KNK03, KLC03
211/407
Connection points
R911335703_Edition 04 Bosch Rexroth AG
