6.7.9 Connection cover: Mounting options
Fig. 6-19: Connection cover: Mounting options
Tightening torque of the mounting screws: 2.5 Nm
6.7.10 Two-piece connection cover
See chapter 14.3 "Two-piece connection cover" on page 374.
IndraDrive Mi Drive Systems with KCU02, KSM02,
KMS02/03, KMV03, KNK03, KLC03
213/407
Connection points
R911335703_Edition 04 Bosch Rexroth AG
