8.2.6 KLC03 type plate
Arrangement
Fig. 8-11: Type plate arrangement
A second type plate is enclosed with the product.
IndraDrive Mi Drive Systems with KCU02, KSM02,
KMS02/03, KMV03, KNK03, KLC03
271/407
Identification
R911335703_Edition 04 Bosch Rexroth AG
