● E3 (X38.4): +24 V to activate drive enable
See Functional Description of firmware → "Easy startup mode".
Analog outputs
KSM/KMS have no analog outputs!
Oscilloscope function
It is possible to use the oscilloscope function integrated in the drive and
described in the Functional Description of the firmware!
See Functional Description of firmware → "Oscilloscope function".
Patch function
With the patch function you can read or write controller-internal memory cells.
See Functional Description of firmware → "Patch function".
Monitoring function
The monitoring function provides extended diagnostic possibilities.
See Functional Description of firmware → "Monitoring function".
Logbook function
With the logbook function you can reproduce the internal firmware sequence.
See Functional Description of firmware → "Logbook function".
IndraDrive Mi Drive Systems with KCU02, KSM02,
KMS02/03, KMV03, KNK03, KLC03
355/407
Commissioning, operation, diagnostics and maintenance
R911335703_Edition 04 Bosch Rexroth AG
