6.6.12 XG34, mains contactor control and feedback contacts (KNK03)
View Connection Function
1 Mains contactor control
Connection to mains filter (XG34.1/2)
2
3 Mains contactor feedback (N/O contact)
Connection to mains filter (XG34.3/4)
4
Tab. 6-68: Pin assignment
Mechanical data
Spring terminal (connector) Unit max.
Connection cable
Stranded wire
mm
2
1.5
AWG 16
Stripped length mm 10
Tab. 6-69: Mechanical data
Cables
Description Value
Order type RKH0800
Maximum allowed length 1 m
Tab. 6-70: Cables
IndraDrive Mi Drive Systems with KCU02, KSM02,
KMS02/03, KMV03, KNK03, KLC03
205/407
Connection points
R911335703_Edition 04 Bosch Rexroth AG
