1.3.6 KMV03 supply unit
KMV03 type code
Short type designation 1 2 3 4 5 6 7 8 9
1
0 1 2 3 4 5 6 7 8 9
2
0 1 2 3 4 5 6 7 8 9
3
0 1 2 3 4 5 6 7 8 9
4
0
Example: K M V 0 3 . 1 R - B 0 0 0 7 - P - D 7 - E T - N N N N - F W
① ② ③④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪
① Product:
KMV = Supply module
② Series:
03 = 3
③ Design:
1 = 1
④ Power supply unit:
R = Regenerative
⑤ Cooling type:
A = Natural convection (exterior heat sink)
B = Thermal interface (cold plate mounting)
I = Thermal interface (insulated mounting)
W = Forced cooling (exterior heat sink, mounted fan)
⑥ Rated power:
0007 = 7.5 kW
1)
01K5 = 1.5 kW
2)
05K0 = 5 kW
3)
06K0 = 6 kW
4)
⑦ Degree of protection:
P = IP65
⑧ Nominal DC bus voltage:
D7 = DC 750 V
⑨ Master communication:
ET = Multi-Ethernet
⑩ Other design:
NNNN = None
⑪ Firmware:
FW = Firmware is required to operate the device
1) Rated power "0007" only with cooling type "B"
2) Rated power "01K5" only with cooling type "I"
3) Rated power "05K0" only with cooling type "A"
4) Rated power "06K0" only with cooling type "W"
Tab. 1-12: KMV03 type code
IndraDrive Mi Drive Systems with KCU02, KSM02,
KMS02/03, KMV03, KNK03, KLC03
21/407
System presentation
R911335703_Edition 04 Bosch Rexroth AG
