5.5.3 Basic data
Control voltage
Control voltage supply data
Description Symbol Unit
KMV03.1R-
A05K0-P-D7-
ET-NNNN
KMV03.1R-
B0007-P-D7-
ET-NNNN
KMV03.1R-
I01K5-P-D7-
ET-NNNN
KMV03.1R-
W06K0-P-D7-
ET-NNNN
Control voltage input
1)
U
N3
V DC 24 V ±20 %
Max. inrush current at 24 V supply
I
EIN3_max
A 10.00
Pulse width of I
EIN3
t
EIN3Lade
ms < 1000
Input capacitance
C
N3
mF 11.00
Rated power consumption control
voltage input at U
N3
P
N3
W 18
Latest amendment: 2019-08-08*
1) 2) 3) Observe supply voltage for motor holding brake
Tab. 5-12: KMV - Control voltage supply data
