Bosch rexroth KMS03.1B-A036-P-D7-ET-END-L3-TO-FW User Manual

5.3 KMS02 near motor servo drive
5.3.1 KMS02 data sheet
KMS data sheet
Description Symbol Unit KMS02.1B-A018-P-D7-ET-NNN-NN-NN
Listing in accordance with UL standard UL 508C
Listing in accordance with CSA standard C22.2 No. 274-13
UL files E134201
Ambient temperature range for operation
with nominal data
T
a_work
°C 0...40
Degree of protection according to
IEC60529
Ambient conditions according to
UL50/50E
4X Indoor Use Only
Mass m kg 2.50
Control voltage data
Control voltage input
1)
U
N3
V DC 30...42
Power consumption control voltage input
at U
N3
2)
P
N3
W 17.5
Power section data
Short circuit current rating SCCR A rms 42000
Rated input voltage, power
3)
U
LN_nenn
V DC 540...750
Capacitance in DC bus
C
DC
mF 0.02
Capacitance against housing
9)
C
Y
nF 118+100
Rated input current
I
LN
A 7.3
Allowed switching frequencies
4)
f
s
kHz 4, 8
Maximum bypass current A Bypass max. 25 A
Power dissipation at continuous current
and continuous DC bus power
respectively
5)
P
Diss_cont
W 50.00
Power section data - output
Output voltage, fundamental wave in
V/Hz (U/f) control
U
out_eff
V
U
DC
* 0.71
Output voltage, fundamental wave in
closed-loop operation
U
out_eff
V -
Rise of voltage at output with U
LN_nenn
and
7.5 m motor cable length phase-phase
(10‑90%)
6)
dv/dt kV/µs 5.00
Latest amendment: 2018-02-22*
IndraDrive Mi Drive Systems with KCU02, KSM02,
KMS02/03, KMV03, KNK03, KLC03
81/407
Technical data of the components
R911335703_Edition 04 Bosch Rexroth AG

Bosch rexroth KMS03.1B-A036-P-D7-ET-END-L3-TO-FW Specifications

General

Brand	Bosch
Model	rexroth KMS03.1B-A036-P-D7-ET-END-L3-TO-FW
Category	DC Drives
Language	English
