7.1.6 Control voltage power requirement 42 V
Power components Symbol Power
requirement [W]
Explanation
Basic power of the component P
Basic
15 Component: KSM, KMS, KMV, …
Digital inputs/outputs P
IO
2.5 Connection point X37, X38
The power component is only available when the
digital outputs are used without an additional external
24V supply.
Optional safety technology S3 P
S3
2.5 Safety option "Safe Motion (without SBC)"
Optional safety technology SD P
SD
2.5 Safety option "Safe Motion"
Optional master communication
output coupling TO
P
TO
- No additional power required
Optional external master
communication ES
P
ES
-
Optional safety technology L3 P
L3
- Power requirement contained in basic power of the
component P
Basic
Motor holding brake KSM…041 P
Br
12
Motor holding brake KSM…061 18
Motor holding brake KSM…071 24
Motor holding brake KSM…076 24
Motor holding brake KMS n.s. See specification of motor holding brake of the
connected motor
Tab. 7-1: Control voltage power requirement
Control voltage power requirement
of one component
P
N3_42V
= P
Basic
+ P
IO
+ P
S3/SD
+ P
Br
Control voltage power requirement
of multiple components of a drive
line
P
total
= ΣP
N3_42V
IndraDrive Mi Drive Systems with KCU02, KSM02,
KMS02/03, KMV03, KNK03, KLC03
219/407
Notes on project planning
R911335703_Edition 04 Bosch Rexroth AG
