6.3.7 X141, safety technology and service input "release brake"
All distributed drives and supply units feature the connection point X141,
independent of the device options installed.
Fig. 6-12: X141
The function of the connection point differs according to the devices and
device options:
● Distributed drive:
– chapter "X141, safety technology Safe Torque Off" on page 174
– chapter "X141, safety technology Safe Motion (S3, SD options)" on
page 176
– chapter "X141, without safety technology" on page 177
● Distributed supply unit:
– chapter 6.6.5 "X141, safety technology (KMV03)" on page 200
IndraDrive Mi Drive Systems with KCU02, KSM02,
KMS02/03, KMV03, KNK03, KLC03
173/407
Connection points
R911335703_Edition 04 Bosch Rexroth AG
