1.3.8 KLC03 DC bus capacitor unit
KLC03 type code
Short type designation 1 2 3 4 5 6 7 8 9
1
0 1 2 3 4 5 6 7 8 9
2
0 1 2 3 4 5 6 7 8 9
3
0 1 2 3 4 5 6 7 8 9
4
0
Example: K L C 0 3 . 1 N - B 0 4 M 7 - P - D 7 - N N N N
①② ③④ ⑤ ⑥ ⑦ ⑧ ⑨
â‘ Product:
KLC03 = DC bus capacitor unit
â‘¡ Series:
03 = 3
â‘¢ Design:
1 = 1
â‘£ Other properties:
N = None
⑤ Cooling type:
A = Natural convection (exterior heat sink)
B = Thermal interface (cold plate mounting)
W = Forced cooling (exterior heat sink, mounted fan)
â‘¥ Nominal capacitance:
04M7 = 4.7 mF
⑦ Degree of protection:
P = IP65
⑧ Nominal DC bus voltage:
D7 = DC 750 V
⑨ Other design:
NNNN = None
Tab. 1-14: KLC03 type code
1.3.9 Firmware
Type code: see Functional Description of firmware
IndraDrive Mi Drive Systems with KCU02, KSM02,
KMS02/03, KMV03, KNK03, KLC03
23/407
System presentation
R911335703_Edition 04 Bosch Rexroth AG
