5.6 KLC03 DC bus capacitor unit
5.6.1 KLC03 data sheet
Technical data
Description Symbol Unit KLC03.1N-A04M7 KLC03.1N-B04M7 KLC03.1N-W04M7
Mass m kg 17 12 17
Allowed mounting position - - G1 G1, G2, G3, G4 G1
Allowed input voltage U
DC
V DC 254 … 750
DC bus capacitance C
DC
mF 4.7 ±20%
Power dissipation at continuous
current and continuous DC bus power
respectively
P
Diss_cont
W 30
Maximum discharge time from
U
R_DC_On
to DC 50 V
t
entl_ZK
sec 660
Allowed input current at L+ L- I
max(rms)
A 25
Insulation resistance (at DC 500 V) R
is
Mohm > 50
Tab. 5-16: KLC03 - technical data
IndraDrive Mi Drive Systems with KCU02, KSM02,
KMS02/03, KMV03, KNK03, KLC03
101/407
Technical data of the components
R911335703_Edition 04 Bosch Rexroth AG
