RKH0220
X103.1 X103.2
RKH0222
X103.1 X103.2
1) R-End plug-in connector for RKH0021, RKH0120, RKH0121,
RKH0220
2) R-End plug-in connector for RKH0222
3) View to mating side
Tab. 5-36: Parts of ready-made hybrid cables without communication from
KSM/KMS to KSM/KMS
136/407
Technical data of the components
IndraDrive Mi Drive Systems with KCU02, KSM02,
KMS02/03, KMV03, KNK03, KLC03
Bosch Rexroth AG R911335703_Edition 04
