Short type designation 1 2 3 4 5 6 7 8 9
1
0 1 2 3 4 5 6 7 8 9
2
0 1 2 3 4 5 6 7 8 9
3
0 1 2 3 4 5 6 7 8 9
4
0
Example: K S M 0 2 . 1 B - 0 6 1 C - 3 5 N - M 1 - H P 0 - E T - N N - D 7 - N N - F W
①② ③④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩⑪⑫ ⑬ ①⑮ ⑯ ⑰
â‘« Holding brake:
0 = Without holding brake
2 = Holding brake, DC 24 V, electrically releasing
⑬ Master communication:
ET = Multi-Ethernet
â‘ Safety option:
L3 = Safe Torque Off (STO)
NN = Without safety technology
S3 = Safe Motion (without SBC)
SD = Safe Motion (with SBC)
â‘® Supply voltage:
D7 = DC 750 V
⑯ Other design:
AE = ATEX version, external master communication Multi-Ethernet (2 × M12)
AN = ATEX version
AT = ATEX version, Multi-Ethernet output coupling (2 × M12)
ES = External master communication Multi-Ethernet (2 × M12)
NN = None
TO = Multi-Ethernet output coupling (2 × M12)
â‘° Firmware:
FW = Firmware has to be ordered as a separate subposition
Tab. 1-5: KSM02 type code
Size Length Winding
24 35 42 61
041 C – – ✓ –
061 C – ✓ – ✓
071 C ✓ ✓ – –
076 C – ✓ – –
Tab. 1-6: Winding
IndraDrive Mi Drive Systems with KCU02, KSM02,
KMS02/03, KMV03, KNK03, KLC03
15/407
System presentation
R911335703_Edition 04 Bosch Rexroth AG
