IndraDrive C/Cs capacitances
Component C
Y
[nF]
HCS01.1E-W0003-A-02 136
HCS01.1E-W0006-A-02 136
HCS01.1E-W0009-A-02 136
HCS01.1E-W0013-A-02 136
HCS01.1E-W0018-A-02 200
HCS01.1E-W0005-A-03 136
HCS01.1E-W0008-A-03 136
HCS01.1E-W0018-A-03 200
HCS01.1E-W0028-A-03 200
HCS01.1E-W0054-A-03 200
HCS02.1E-W0012 200
HCS02.1E-W0028 200
HCS02.1E-W0054 200
HCS02.1E-W0070 200
HCS02.1E-W0100 200
HCS03.1E-W0070 200
HCS03.1E-W0150 200
HCS03.1E-W0210 200
HCS03.1E-W0280 200
HCS03.1E-W0350 200
Tab. 14-14: IndraDrive C/Cs capacitances
IndraDrive M capacitances
Component C
Y
[nF]
HMS01.1N-W0020 136
HMS01.1N-W0036 136
HMS01.1N-W0054 136
HMS01.1N-W0070 136
HMS01.1N-W0110 200
HMS01.1N-W0150 200
HMS01.1N-W0210 200
HMS01.1N-W0300 200
HMS01.1N-W0350 200
HMS01.2N-W0028 136
HMS01.2N-W0054 136
HMD01.1N-W0012 136
IndraDrive Mi Drive Systems with KCU02, KSM02,
KMS02/03, KMV03, KNK03, KLC03
379/407
Appendix
R911335703_Edition 04 Bosch Rexroth AG
