Daedong DSC48 - Page 212

5
-16
Apr. 2007
DSC48
F. BATTERY CABLE
(Check every 50 hours)
1. When replenishing the battery with electrolyte, use dis-
tilled water and do not overfi ll.
2. Use only the specifi ed battery.
3. When disconnecting the battery cables, disconnect
the negative (ground) cable fi rst. When connecting the
cables, connect the positive cable fi rst.
417W537A
(1) Battery (3) Positive cable
(2) Negative cable
G. AIR CLEANER ELEMENT
(Check every 50 hours and replace every 300 hours)
• Before daily operation, remove any dust by blowing air
from the inside of element or tapping it lightly. (When
using compressed air, its pressure should not exceed 5
kgf/cm
2
.)
417W538A
(1) Air cleaner (2) Wing bolt
H. CLEANING AIR FILTER
1. When dust is accumulated over the mark on the side of
the air fi lter, remove the wing nut and remove the dust
as shown in the fi gure.
417W539A
(1) Air fi lter (3) Dust
(2) Wing nut
