Power Supply Circuit Board
6-8 72A-1589 Rev. C 02/01
D
DD
D
R
RR
R
A
AA
A
F
FF
F
T
TT
T
3
33
3
/
//
/
5
55
5
/
//
/0
00
0
1
11
1
Power Supply Circuit Board
The power supply board is installed in slot 11. The board has three LEDs
designated D1, D2 and D3 that are visible from the rear of the chassis.
Refer to Table 6.4.
Fuses
In addition to the LEDs, two fuses are located on the power supply board
for the AC input (F3 and F4 designation).
• For a 115 V power supply, the fuse value is 20 A.
• For a 230 V power supply, the fuse value is 10 A.
Table 6.4 Power Supply Board LED Indicators
Power
Supply
Board LED
Indication
PSERR
[D1]
Illuminates green for the first 30 seconds after power up,
then is OFF after completing the Power Supply power
up sequence.
• The power supply has its own power up sequence.
The PSERR LED performs this sequence even if the
CPU board is not installed.
LOFLOW
[D2]
This LED is normally OFF.
If illuminating green, check the following:
• Check the power supply voltages on the CPU PCB.
• Check for proper fan operation.
BATTON
[D3]
Illuminates green when the Battery Simulator is
instructed to turn ON, otherwise it is OFF.
• Illuminating green indicates only that the Battery
Simulator is instructed to turn ON, and is not an
indication of proper operation.
