Instrument Front Panel
7-12 72A-1589 Rev. C 02/01
D
DD
D
R
RR
R
A
AA
A
F
FF
F
T
TT
T
3
33
3
/
//
/
5
55
5
/
//
/0
00
0
1
11
1
Except for W16, all the wires in the F6150 connect to the
communications board or the output terminal board on the instrument
front panel. Table 7.2 lists these wires and their connections.
Table 7.2 Wire Connections
Wire Number Connects From Connects To
W2 Communications board Logic I/O board
W3 Output Terminal board Logic I/O board
W4 Output Terminal board Logic I/O board
W5 Output Terminal board Logic I/O board
W6 Communications board CPU board
W7 Communications board Analog I/O board
W8 Output Terminal board Motherboard
W16 Power supply Battery simulator
W18 Power Supply Output Terminal board
