F6000 Family of Power System Simulators User Guide
72A-1589 Rev. C 02/01 7-27
D
DD
D
R
RR
R
A
AA
A
F
FF
F
T
TT
T
3
33
3
/
//
/
5
55
5
/
//
/0
00
0
1
11
1
Table 7.5 lists all the cables used with the F6150. If a system failure is
traced to a particular cable, ensure that the cable is properly seated and
connected before replacing it. Contact Doble Customer Service to order
replacement cables.
Table 7.5 Cable and Adapter Replacement List
Part Number Description
05B-0616-01 Assy, Cable, I Output
05B-0617-01 Assy, Cable, V Output
05B-0618-01 Assy, Cable, Logic I/O
05B-0619-01 Cable, Adapt #4 R LUG-3x4 mm, F
181-0088 Cord, Power, 14AWGX3, USA Plug
181-0118 Cable, RG58C/U, 500 HM 20 A M/M
212-0527 Adapter, SM, Spade LUG-4 mm, Black
212-0528 Adapter, SM, Spade LUG-4 mm, Red
212-0529 Adapter, SM, Spade LUG-4 mm, White
401-0167 Cable, RS-232, INSTR-PC 10 Ft/3.05 Meter
401-0157 Terminator, In-line 50 Ohm BNC
