F6000 Family of Power System Simulators User Guide
72A-1589 Rev. C 02/01 F-17
D
DD
D
R
RR
R
A
AA
A
F
FF
F
T
TT
T
3
33
3
/
//
/
5
55
5
/
//
/0
00
0
1
11
1
75 VA Convertible Voltage Sources at 50 or 60 Hz
To perform the Phase Shift test on a 75 VA Convertible Voltage source at
50 or 60 Hz:
1. Configure the F6000 for six voltages using the Pre-set Configurations
on the F6000 Configuration display in ProTesT.
2. Set all six ranges to 75 V and all amplitudes to 75 V.
3. Set all six phase angles to 0
°
.
4. Connect source VA to the reference input of the phase meter.
5. Connect source VB to the signal input of the phase meter.
6. Turn both sources ON.
7. Verify that the phase angle is within ±0.25
°
.
8. Turn OFF the signal source.
9. Repeat.
Figure F.12 shows a typical setup for phase testing six voltage sources.
The phase meter shown is an Arbiter model 931 A.
Figure F.12 Test Setup for Phase Testing Six Voltage Sources
