Table 6.6 Common Source Errors
Error Explanation Action
Transient over 1.5
seconds
Hardware disables the source. Reboot the system.
Peak current Hardware disables the source.
Normally, this error does not occur
for a current source. It typically
means a voltage source is
overloaded (as, for example, when
a short circuit occurs at high
amplitude).
Reduce the voltage.
Clip Fast A current source cannot drive a
load.
Clip Slow A current source cannot drive a
load.
Distortion Software processing of error
feedback ADCs.
A current source cannot drive a
load.
Battery Power Limit Battery simulator load has exceeded
maximum power output of 60 W.
Reduce the battery simulator load.
Battery Current
Limit
Battery simulator load has exceeded
maximum current limit of 1.25 A at
48 volts.
Reduce the battery simulator load.
