Hardware Architecture
1-2 72A-1589 Rev. C 02/01
D
DD
D
R
RR
R
A
AA
A
F
FF
F
T
TT
T
2
22
2
/
//
/
2
22
2
0
00
0
/
//
/
0
00
0
1
11
1
Hardware Architecture
The components of the F6000 Instrument are:
• Front Panel
• Logic I/O Board
•CPU Board
•Analog I/O Board
• Three Current Amplifiers
• Three Voltage Amplifiers
• Power Supply
• Battery Simulator
• Four Cooling Fans
Figure 1.2 shows the location of these components in the instrument.
Figure 1.2 Instrument Architecture
Front Panel
Logic I/O Board
CPU Board
Current Amplifiers
Voltage Amplifiers
Power Supply
Battery Simulator
Cooling
Analog I/O Board
Fans
