Source Outputs
The Source Outputs section of the relay F6150 front panel contains
outputs for AC/DC voltage and current sources, and a battery simulator
that supplies DC power. It also contains an Instrument Display that shows
key information about the operation of the instrument (Figure 2.1
on page 2-1).
Instrument Display
On bootup, the messages in the Instrument Display cycle in a predictable
and recognizable pattern. This pattern is disrupted if the F6000
Instrument fails its internal diagnostic test. The F6000 performs a set of
internal diagnostics to check the integrity of the system's memory, data,
and communication paths. It also checks the integrity of all the system
modules. After a successful bootup, the F6000 Instrument Display shows
the following information:
• CPU serial number
• Firmware revision currently installed
• Options enabled
• Instrument’s IP address for purposes of network communications
• Status of the GPS receiver (if Option 6885 is installed and
Receiver Option 6895 is powered up and connected to the
F6150)
During normal operation, the Instrument Display shows source names
and the layout of the sources. When any source is on or enabled, it
shows the amplitude and phase angle of the source for up to six sources.
N
OTE
When a source is enabled, the source label uses a lower case identifier
(for example, va, vb, vc, i1, i2, and i3). When a source is on, the source
label uses an upper case identifier (for example, VA, VB, VC, I1, I2,
and I3).
