doble F6000 - Battery Simulator Function; Auxiliary Functions Overview

Battery Simulator
2-6 72A-1589 Rev. C 02/01
D
DD
D
R
RR
R
A
AA
A
F
FF
F
T
TT
T
2
22
2
/
//
/
1
11
1
5
55
5
/
//
/
0
00
0
1
11
1
Figure 2.5 illustrates the front panel source configuration when three
150 VA voltage sources are split into six 75 VA sources.
Figure 2.5 Six 75 VA Sources
Battery Simulator
The battery simulator can be used to power digital relays and may be set
to provide 48, 125, or 250 V of DC output at 60 W.
Auxiliary Functions
Other functions on the F6150 front panel include:
• Communications
• Logic Inputs
• Logic Outputs
• DC Meter Inputs
• Power Connection and Switch
Convertible Sources
(Voltage or Low Current) Current Sources
Volts or
Amps
150 VA
Volts or
Amps
150 VA
Amps
75 VA
Amps
75 VA
Amps
75 VA
Amps
75 VA
Amps
75 VA
Amps
75 VA
150 VA Sources
75 VA Sources
Terminals for
Return Lines
(Red)
(Black)
(Red)
