F6000 Family of Power System Simulators User Guide
72A-1589 Rev. C 02/01 2-5
D
DD
D
R
RR
R
A
AA
A
F
FF
F
T
TT
T
2
22
2
/
//
/
1
11
1
5
55
5
/
//
/
0
00
0
1
11
1
These six sources can be switched to eight sources by splitting two of the
150 VA sources into four 75 VA sources (Figure 2.4).
Figure 2.4 Four 150 VA Sources and Four 75 VA Sources
The source outputs on the F6150 Instrument front panel include
terminals for 150 VA and 75 VA sources as well as terminals for return
lines:
• The six red terminals in the first row of outputs supply 150 VA
of power.
The first set of three 150 VA outputs are convertible sources.
Use these as voltage sources or optionally as low current sources.
The fourth, fifth, and sixth outputs are 150 VA current sources.
• The six black terminals in the second row are for return lines.
When a 150 VA source is split into two 75 VA sources, the return
line for both sources uses the common terminal in the middle
row.
• The six red terminals in the third row of outputs supply 75 VA of
power when a 150 VA source is split.
Convertible Sources
(Voltage or Low Current) Current Sources
Volts or
Amps
150 VA
Volts or
Amps
150 VA
Volts or
Amps
150 VA
Volts or
Amps
150 VA
Amps
150 VA
Amps
150 VA
Vo lt s or
Amps
75 VA
Vo lt s or
Amps
75 VA
Amps
75 VA
Amps
75 VA
150 VA Sources
75 VA Sources
Terminals for
Return Lines
(Red)
(Black)
(Red)
Convertible Sources
(Voltage or Low Current) Current Sources
Volts or
Amps
150 VA
Volts or
Amps
150 VA
Volts or
Amps
150 VA
Volts or
Amps
150 VA
Amps
150 VA
Amps
150 VA
Volts or
Amps
75 VA
Volts or
Amps
75 VA
Amps
75 VA
Amps
75 VA
150 VA Sources
75 VA Sources
Terminals for
Return Lines
