Compliance Voltage and Current Range
The compliance voltage of a current source is the highest voltage into
which the current source can inject current. The formula for calculating
the compliance voltage of a current source is:
V = P
÷
I
where P is the VA rating of the current source and I is the current range.
For example, if a source is rated at 150 VA and the current range is set at
7.5 A, the compliance voltage for the source is 20 V.
N
OTE
For maximum compliance voltage, use the lowest current range that
can produce the desired test current. For example, if the test requires
5 A, set the range at 7.5 A, not 15 A.
Table C.1 through Table C.4 show range settings and compliance
voltages for all common source configurations. See Appendix G ”F6150
Specifications”, for more information on range settings.
Table C.1 Maximum Compliance Voltage for Low Current Source Combinations
Maximum Compliance Voltage
Current Range 75 VA Source 150 VA Source 300 VA Source 450 VA Source
0.5 A 150 V 300 V — —
1.0 A 75 V 150 V 300 V —
1.5 A — — — 300 V
2.0 A — 75 V 150 V —
3.0 A — — — 150 V
4.0 A — — 75 V —
6.0 A — — — 75 V
