Circuit Board Replacement
Doble Customer Service may recommend that a circuit board be
replaced to remedy an operating problem. None of the solid-state circuit
boards requires user calibration or adjustment. Table 7.3 contains a list of
slot numbers and circuit boards in the F6150.
N
OTE
Remove or insert printed circuit assemblies carefully to avoid damage
to their mating connectors. To ensure that new boards go into their
correct locations, replace them individually.
Contact Doble for a replacement circuit board, or obtain one from your
company inventory of replacement parts, if available.
To replace a circuit board:
1. Turn the instrument off.
2. Remove the power cord.
3. Disconnect all external cables from the instrument.
4. Remove the instrument cover.
5. Remove the capture rail.
Table 7.3 Circuit Boards in the F6150
Slot Number Circuit Board
Slot 1 Logic I/O board
Slot 2 Spare slot
Slot 3 CPU board
Slot 4 Analog I/O board
Slot 5 Current amplifier #1
Slot 6 Current amplifier #2
Slot 7 Current amplifier #3
Slot 8 Voltage amplifier #1
Slot 9 Voltage amplifier #2
Slot 10 Voltage amplifier #3
Slot 11 Power supply
