doble F6000 - Table C.2 Maximum Compliance Voltage for Low Transient Current Source Combinations; Table C.3 Maximum Compliance Voltage for Current Source Combinations

Compliance Voltage and Current Range
C-4 72A-1589 Rev. C 02/01
D
DD
D
R
RR
R
A
AA
A
F
FF
F
T
TT
T
3
33
3
/
//
/
5
55
5
/
//
/0
00
0
1
11
1
Table C.2 Maximum Compliance Voltage for Low Transient Current
Source Combinations
Maximum Compliance Voltage
Current Range 97.5 VA Source 195 VA Source 390 VA Source 585 VA Source
0.75 A 130 V 260 V — —
1.5 A 65 V 130 V 260 V —
2.25 A — — — 260 V
3.0 A — 65 V 130 V —
4.5 A — — — 130 V
6.0 A — — 65 V —
9.0 A — — — 65 V
Table C.3 Maximum Compliance Voltage for Current Source Combinations
Maximum Compliance Voltage
Current Range 75 VA Source 150 VA Source 300 VA Source 450 VA Source
7.5 A 10 V 20 V 40 V 60 V
15 A 5 V 10 V 20 V 30 V
22.5 A — — — 20 V
30 A — 5 V 10 V —
45 A — — — 10 V
60 A — — 5 V —
90 A———5 V
