doble F6000 - Current Source Specifications List

F6000 Family of Power System Simulators User Guide
72A-1589 Rev. C 02/01 G-3
D
DD
D
R
RR
R
A
AA
A
F
FF
F
T
TT
T
2
22
2
/
//
/
2
22
2
1
11
1
/
//
/
0
00
0
1
11
1
Current Sources
Source Configurations
Ranges and Resolution
150 VA Source
Each 150 VA current source can be split into two 75 VA sources. Two
150 VA current sources can be combined into one 300 VA current
source. Three 150 VA current sources can be combined into one 450 VA
current source.
75 VA Source
Output Power Continuous Output Power Transient for 1.5 Sec.
6*75 VA sources 6*112 VA sources
3*150 VA sources 3*225 VA sources
1*450 VA source 1*675 VA source
1*300 VA and 1*150 VA source 1*450 VA and 1*225 VA source
Ranges (Resolution)
AC Current
1.5 Seconds Transient
Continuous Power
15, 30 A (0.001 A), 60 A rms (0.01 A)
7.5,15 A (0.001A), 30 A rms (0.01A)
DC Current
1.5 Seconds Transient
Continuous Power
10, 20, 40 ADC (0.01 A)
5 A (0.001A), 10, 20 ADC (0.01 A)
Ranges (Resolution)
AC Current
1.5 Seconds Transient
Continuous Power
15, 30 A rms (0.001 A)
7.5,15 A rms (0.001 A)
DC Current
1.5 Seconds Transient
Continuous Power
10, 20 ADC (0.01 A)
5 A (0.001A), 10 ADC (0.01 A)
