Options
Several options for the F6000 Instrument are available:
Option F6810 High power convertible voltage/current sources.
Provides three low current/high compliance
voltage sources for testing high burden
electromechanical relays.
Option F6909 Control Panel Enable. Permits the ProTesT F6000
Control Panel to communicate with the F6000
Instrument.
Option F6910 Simulator control and automation module. Use
with ProTesT software or third party software.
Option F6885 Global Positioning System (GPS) satellite receiver
interface. GPS antenna (Option F6895) must be
ordered separately.
Option F6895 GPS antenna. Requires Option F6885, GPS
satellite receiver interface.
The Global Positioning System allows users to synchronize multiple
F6000 simulators at remote locations. The power sources in each
simulator use the one-pulse-per-second signal of the GPS satellite to
synchronize their outputs. GPS synchronization eliminates hardware and
software timing errors in end-to-end testing.
