F6000 Family of Power System Simulators User Guide
72A-1589 Rev. C 02/01 5-7
D
DD
D
R
RR
R
A
AA
A
F
FF
F
T
TT
T
3
33
3
/
//
/
5
55
5
/
//
/0
00
0
1
11
1
Conduct the Test
WARNING The high intensity yellow LED flashes when the battery simulator or any
output source is on or enabled to indicate the potential for dangerous or
fatal voltages.
13. Click the On button for current source I1 (see Figure 5.5
on page 5-6).
The On button in the source table turns red and the Logic Output
indicator light for this source turns red.
14. Click and hold the Ramp/Set up arrow until the relay responds.
The indicator light for Logic Input 1 turns green.
Since AutoSensE is enabled, the amplitude for I1 stops ramping
when the relay responds, and the value is frozen at the pickup value.
15. Click the red On button for current source I1 in the source table to
turn I1 off.
