Appendix G. F6150 Specifications
Convertible Voltage/Current Sources
Each 150 VA Convertible V/I Source can be used as a voltage source or
optionally as a low range, high-power current source.
Source Configurations
Ranges and Resolution
150 VA Source
Each 150 VA convertible V/I source can be split into two 75 VA sources.
Two 150 VA convertible low current sources can be combined into one
300 VA current source. Three 150 VA convertible low current sources
can be combined into one 450 VA current source.
Output Power Continuous Output Power Transient for 1.5 Sec.
6*75 VA sources 6*97.5 VA sources
3*150 VA sources 3*195 VA sources
1*450 VA source 1*585 VA source
1*300 VA and 1*150 VA source 1*390 VA and 1*195 VA source
Ranges (Resolution)
AC Voltage
75, 150, 300 V rms (0.01V)
DC Voltage
106, 212 V (0.01 V), 300 VDC (0.1 V)
AC Current
1.5 Seconds Transient
Continuous Power
0.75, 1.5, 3.0 A rms (0.0001 A)
0.5, 1.0, 2.0 A rms (0.0001 A)
DC Current
1.5 Seconds Transient
Continuous Power
0.53, 1.06 A (0.0001 A), 2.12 ADC (0.001 A)
0.354, 0.707 A (0.0001 A), 1.41 ADC (0.001 A)
