Ranges and Resolution
G-2 72A-1589 Rev. C 02/01
D
DD
D
R
RR
R
A
AA
A
F
FF
F
T
TT
T
2
22
2
/
//
/
2
22
2
1
11
1
/
//
/
0
00
0
1
11
1
75 VA Source
300 VA Source
450 VA Source
Ranges (Resolution)
AC Voltage
75, 150, V rms (0.01 V)
DC Voltage
106, 212 VDC (0.1 V)
AC Current
1.5 Seconds Transient
Continuous Power
0.75, 1.5, A rms (0.0001 A)
0.5, 1.0, A rms (0.0001 A)
DC Current
1.5 Seconds Transient
Continuous Power
0.53, 1.06 ADC (0.0001 A)
0.354, 0.707 ADC (0.0001 A)
Ranges (Resolution)
AC Current
1.5 Seconds Transient
Continuous Power
1.5, 3.0 A, 6.0 A rms (0.0001 A)
1.0, 2.0 A, 4.0 A rms (0.0001 A)
DC Current
1.5 Seconds Transient
Continuous Power
1.06 A (0.0001A), 2.12, 4.24 ADC (0.001 A)
0.707 A (0.0001A), 1.41 A, 2.83 A (0.001 A)
Ranges (Resolution)
AC Current
1.5 Seconds Transient
Continuous Power
2.25, 4.5 A, 9.0 A rms A (0.001 A)
1.5, 3.0 A, 6.0 A rms A (0.001 A)
DC Current
1.5 Seconds Transient
Continuous Power
1.59 A (0.0001 A), 3.18, 6.36 ADC (0.001 A)
1.06 A, 2.12 A, 4.24 ADC (0.001 A)
