F6000 Family of Power System Simulators User Guide
72A-1589 Rev. C 02/01 6-13
D
DD
D
R
RR
R
A
AA
A
F
FF
F
T
TT
T
3
33
3
/
//
/
5
55
5
/
//
/0
00
0
1
11
1
Positive DAC
readback failure
Positive digital to analog converter
readback failure.
Replace the analog I/O board.
Refer to ”Circuit Board
Replacement” on page 7-17.
Negative DAC
readback failure
Negative digital to analog converter
readback failure.
Replace the analog I/O board.
Refer to ”Circuit Board
Replacement” on page 7-17.
Missing/bad Logic
I/O board
The logic I/O circuit board is either
missing or bad.
Replace the logic I/O board. Refer
to ”Circuit Board Replacement”
on page 7-17.
Missing/bad Analog
I/O board
The analog I/O circuit board is
either missing or bad.
Replace the analog I/O circuit
board. Refer to ”Circuit Board
Replacement” on page 7-17.
Missing/bad
(I AMP#0) SLOT 5
The current amplifier in slot 5 is
either missing or bad.
Replace the current amplifier
board in slot 5. Refer to ”Circuit
Board Replacement”
on page 7-17.
Missing/bad
(I AMP#1) SLOT 6
The current amplifier in slot 6 is
either missing or bad.
Replace the current amplifier
board in slot 6. Refer to ”Circuit
Board Replacement”
on page 7-17.
Missing/bad
(I AMP#2) SLOT 7
The current amplifier in slot 7 is
either missing or bad.
Replace the current amplifier
board in slot 7. Refer to ”Circuit
Board Replacement”
on page 7-17.
Missing/bad
(V AMP#0) SLOT 8
The voltage amplifier in slot 8 is
either missing or bad.
Replace the voltage amplifier
board in slot 8. Refer to ”Circuit
Board Replacement”
on page 7-17.
Missing/bad
(V AMP#1) SLOT 9
The voltage amplifier in slot 9 is
either missing or bad.
Replace the voltage amplifier
board in slot 9. Refer to ”Circuit
Board Replacement”
on page 7-17.
Table 6.5 Hardware Errors (Continued)
Error Message Description Action
