F6000 Family of Power System Simulators User Guide
72A-1589 Rev. C 02/01 4-21
D
DD
D
R
RR
R
A
AA
A
F
FF
F
T
TT
T
3
33
3
/
//
/
5
55
5
/
//
/0
00
0
1
11
1
Click OK to close the Triggers display and return to the Timers tab
(Figure 4.10 on page 4-16). The trigger named Trigger 1 appears in both
the Start on source and the Stop on source pick lists.
Start on source The Start on source pick list contains the voltage
and current sources from the source table, plus the
defined triggers. Click the source or trigger in the
list required by the test protocol.
Start condition The Start condition pick list contains three events
or transitions: Off to On, On to Off, and On
Change. The On Change option permits time tests
that are initiated when there is a step change in the
selected source variables. Click the start condition
required by the test protocol. When the source or
trigger selected in Start on source meets the
specified start condition, the timer starts.
Stop on source The Stop on source pick list contains the voltage
and current sources from the source table, plus the
defined triggers. Select the source or trigger from
the list required by the test protocol.
Stop condition The Stop condition pick list contains two events or
transitions – Off to On, and On to Off. Click the
stop condition required by the test protocol. When
the source or trigger selected in Stop on source
meets the specified stop condition, the timer stops.
N
OTE
The timer start and stop conditions apply only to the voltage and
current sources. If a trigger is selected in Start on source, the Start
condition pick list is grayed out. Similarly, if a trigger is selected in Stop
on source, the Stop condition pick list is grayed out.
