System components
file:///D|/Manuales/Para%20recolocar/MOTOS/DUCATI/DUCATI/M796/wsm/EN/M796_ABS_11_6_12.35.1.html[11/12/2015 18:40:26]
Important
Do not use spark plugs with inadequate thermal rating or incorrect thread length. The spark plug must be securely
installed. If a spark plug is loose, it can overheat and damage the engine.
Spark plug type:
Make: CHAMPION
Type: RA6HC
Alternative:
Make: NGK
Type: DCPR8E
Coil
An inductive discharge ignition system is used. Coil operation is governed by the M3C electronic control unit, which
calculates the ignition advance. The power module (integrated in the electronic control unit) also guarantees constant
energy coil charge, by adjusting the dwell time.
The horizontal head coil (1) is mounted under the airbox in order to remove it you shall first remove the left-hand side
conveyor cover (Sect. 6 - 3,
Starter contactor).
