Refit the left-hand side conveyor (Sect. 6 - 3, Starter contactor).
Refit the fuel tank (Sect. 8 - 2,
Refitting the fuel tank).
Refit the tank covers (Sect. 5 - 2,
Refitting the fuel tank fairings).
Refit the seat (Sect. 5 - 3,
Refitting the seat).
For the correct layout of the coil leads, please refer to the following tables.
Note
To check the coils for faults, use the DDS diagnosis instrument and follow the instructions given in the paragraph “Guided
diagnosis“ (Sect. 6 - 13).
Positioning of the HT leads
