Duplo Duprinter DP-43S - Page 324

324
c HELP Mode Function and Operation Procedures
chap.7
S
DOWN information is displayed : [01
**
] and [02
**
]
Details of the error contents
S
JAM information is displayed : [03
**
]
H-21
(1) ADF error code displayHELP mode
01**
02**
DOWN information display
03**
JAM information display
Cord Description and Countermeasures Operation
0102
0202
• Belt motor or belt clock is defective.Self-
check.
Operation stops
0104
0204
• Paper ejection motor clock is defective.Self-
check.
0111
0211
• Sensor level is defective.Self-check.
0121
0221
• The IPC is defective.Transmisstion is not fin-
ished within a fixed time.Self-check.
Cord Item Description
0301
Document mis-
feed:
After paper feeding motor (M1) comes on, and
before paper feedsensor S3 detects a document,
document detection sensor S1goes OFF. (2nd sheet
onward.)
0302
Paper feed
delay:
3 seconds after paper feeding motor comes on,
paper feed sensorS3 has not detected forward edge
of document. (2nd sheetonward.)
0303
Registering
delay:
During document separation, registering sensor S2
has notdetected forward edge of document 0.5 sec-
onds after paper feedsensor S3 detects it.
0305
Paper feeding
stop
the bottom end of the document is not detected in a
certain time after the document is fed.
0306
Continuous
paper feeding
Registering sensor S2 detects the document even
after the document is completely fed.
0308
Paper feeding tip
end backward
Registering sensor S2 does not detect the document
at the time of paper feeding start.
0313
Backward
together
Paper ejection sensor S4 is turned off while the
clock is conveyed at the time of paper ejection.
0341
Paper ejection
delay
Paper ejection sensor S4 does not detect the tip end
of the document in a cetain time after paper ejection
starts.
0342
Paper ejection
stop
Paper ejection sensor S4 does not detect the bottom
end of the document in a certain time after the
above is detected.
0381 OPEN The ADF is open while the ADF is working.
0382 Cover open The ADF cover is open while the ADF is working.
0384
Jammed docu-
ment left
Paper feeding sensor S3, registering sensor S2 or
paper ejection sensor S4 detects the document.
0385 Adjustment jam
Conveyance jamming at the time of adjusting the
stop position.
0388 Document left
The left document is detected with the paper ejec-
tion sensor ON by rotating the belt motor reversely
as long as the distance to the paper ejection sensor
S4 before the first feeding.
