EDM Solution 862 - Point ID Codes

Dialler Reporting Formats 125
Point ID Codes
The table below shows the different Point ID Codes and Event Codes that are transmitted to
the base station receiver when using Contact ID Reporting Format. All event codes are fixed
and will always transmit the same code as there are no programming locations made available
to alter these.
Point ID
Number
Event
Description
Event
Code
Explanation Page
Zones
1 - 8
Burglary Zone 130 Burglary 162
Medical Zone 100 24 Hour Medical 163
Panic Zone 120 24 Hour Panic 163
Hold-Up Zone 122 24 Hour Hold-Up 163
Tamper Zone 137 24 Hour Tamper 163
Burglary Zone 133 24 Hour Burglary 164
Fire 110 24 Hour Fire 164
User Codes
1 - 16
Open/Close Report 401
Opening – User #
Closing – User #
151
030
AC Mains Fail 301 AC Power 183
031
Low Battery 309 Battery Test Failure 184
040
Codepad Duress 121 Duress Alarm 180
041
Codepad Panic 120 Panic Alarm 180
046
Codepad Fire 110 Fire Alarm 181
045
Codepad Medical 100 Medical Alarm 181
042
Code Retry Limit Exceeded 421 Access Denied 185
044
Test Report 602 Test Report 187
Zone Specific
1 – 8
Sensor Watch 307 Sensor Self Test Failure 178
Zone Specific
1 - 8
Trouble 380 Sensor Trouble 177
Zone Specific
1 – 8
Bypass 570 Zone Bypass 176
00
Fuse Fail 300 System Trouble 182
Table 47: Point ID Codes
Electronics Design and Manufacturing Pty Limited ISSUE130
