Dialler Information 141
Telephone Line Fault Options
LOCATION 176
0
When programming this location, you will notice that there are four options per location. If
you require options 1, 2, 4 or all of these options, only one number needs to be programmed.
This number is calculated by adding the option bit numbers together. Program a 7 if you
require options 1, 2 and 4 simultaneously (i.e. 1 + 2 + 4 = 7).
Option Description
1
Display FAULT Indicator When Telephone Line Fails
2
Sound Alarm When System Is Armed
4
Sound Alarm When System Is Disarmed
8
Reserved
Table 61: Telephone Line Fault Options
The control panel has the ability to monitor the telephone line. If the telephone line has been
cut or disconnected for more than forty seconds, the control panel will recognise this and the
FAULT
indicator will illuminate on the codepad. The
FAULT
indicator will extinguish once the
telephone line has been restored for more than forty seconds.
Option 2 and 4 will not operate unless option 1 has been enabled.
1
2
4
8
Display FAULT Indicator When Telephone Line Fails
The
FAULT
indicator will flash and the codepad buzzer will beep once every minute if the
control panel detects that the telephone line has been disconnected. Refer to Fault Descriptions
on page 64 for more information.
Sound Alarm When System Is Armed
Option 1 in this location will also need to be selected for this option to operate. If the control
panel detects that the telephone line has been disconnected when the system is armed in
AWAY Mode, STAY Mode 1 or STAY Mode 2, the horn speaker, bell and strobe outputs will
operate.
Sound Alarm When System Is Disarmed
Option 1 in this location will also need to be selected for this option to operate. If the control
panel detects that the telephone line has been disconnected when the system is disarmed, the
horn speaker, bell and strobe outputs will operate.
Reserved
If Options 1, 2 and 4 have been added together, the horn speaker, bell, strobe and
EDMSAT outputs will operate when the system is armed or disarmed.
Electronics Design and Manufacturing Pty Limited ISSUE130
