64
Solution 862
Installation Manual
1
2
3
4
5
6
Fault Descriptions
Low Battery
A low battery fault will register when the battery supply voltage falls below 10.5 volts or when
a dynamic battery test detects a low capacity battery. This fault will clear after a successful
dynamic battery test. A dynamic battery test is performed every four hours once power has
been connected to the control panel and also every time the system is armed in AWAY Mode,
STAY Mode 1 or STAY Mode 2.
When reporting to the base station receiver, the control panel will report a “Battery Test
Failure” report (Contact ID Event Code 309) to indicate the low battery fault condition.
Date and Time
The date and time fault will register every time the control panel has been powered down. This
type of fault will not cause the
FAULT
indicator on the codepad to flash unless the Auto
Arming Time on page 208 has been programmed, otherwise, the date and time fault will only
be indicated when entering fault analysis mode. This fault will clear once the date and time has
been programmed. Refer to Setting The Date and Time on page 104 for further information on
setting the date and time.
Sensor Watch
A sensor watch fault will register because one of the detection devices has stopped working or
has failed to detect movement for the time period programmed whilst the system is disarmed.
The sensor watch fault will clear after the registered zone has been unsealed and resealed
again.
To find out which zone has registered the sensor watch fault, hold down the
5
button whilst
in fault analysis mode to display the zone that has registered the sensor watch fault. Refer to
Sensor Watch Time on page 206 for setting sensor watch time and Zone Options 1 on page 167
for setting zones to be monitored for sensor watch.
When reporting to the base station receiver, a “Self Test Fail” report (Contact ID Event Code
307) will be used to indicate the sensor watch fault.
Horn Speaker Monitor
A horn speaker monitor fault will register when the horn speaker becomes disconnected from
the control panel. This fault will clear when the horn speaker has been reconnected. Refer to
"LOCATION 424" on page 215 to enable monitoring of the horn speaker.
Telephone Line Fault
A telephone line fault will register when the telephone line has been disconnected from the
control panel for more than 40 seconds. This fault can only occur if Option 1 in “LOCATION
176” on page 141 has been selected. The fault will clear once the telephone line has been
reconnected for more than 40 seconds.
E
2
Fault
An E
2
fault will register when the control panel detects an internal checksum error. The
control panel will need to be powered down and defaulted to clear this fault.
ISSUE130 Electronics Design and Manufacturing Pty Limited
