Zone Information 161
Zone Programming
Each zone contains seven locations that are divided into three groups. The first 3 locations
determine how the zone will operate, the next two locations allow various options for each
zone and the last two locations contain the dialler reporting information of each zone.
Zone Operating Information
Zone Type
This location programs the "Zone Type" required (e.g.. Delay-1, Instant, 24 Hour etc).
Zone Pulse Count
This location sets how many times the zone must trigger within the time specified in the "Zone
Pulse Count Time”.
Zone Pulse Count Time
This parameter sets the time period for the number of times the zone must trigger before
activating an alarm.
Zone Options
Zone Options 1
This location controls the zone (e.g.. Lockout Siren, Silent etc).
Zone Options 2
This location controls the zone (e.g.. Isolate In STAY Mode 1, Forced Arming Allowed etc).
Zone Reporting Information
Zone Report Code
If you wish the control panel to transmit zone alarm reports, this location should be
programmed as 1. If you do not wish to transmit zone alarm reports, this location should be
programmed as a 0.
Zone Dialler Options
This location is factory default to report only to receiver 1. You can select each zone to report
on receiver 1, receiver 2, both receiver 1 and receiver 2, receiver 2 only when receiver 1 fails
or no reporting at all. Select the required dialler option from the table below.
Option Description
0
No Report Required
1
Receiver 1
2
Receiver 2
4
Receiver 1 and Receiver 2
8
Receiver 2 Only When Receiver 1 Fails
Table 71: Zone Dialler Options
Electronics Design and Manufacturing Pty Limited ISSUE130
