Solution 862
Installation Manual
Codepad Reporting Options
LOCATION 343
1
Option Description
0
No Report Required
1
Receiver 1
2
Receiver 2
4
Receiver 1 and Receiver 2
8
Receiver 2 Only When Receiver 1 Fails
Table 90: Codepad Reporting Options Location
This location is factory default to report only to receiver 1. You can select whether the
codepad reporting options will report on receiver 1, receiver 2, both receiver 1 and receiver 2,
receiver 2 only when receiver 1 fails or no reporting at all.
System Status – Fuse Fail Report
LOCATION 344 - 345
Location Description
344
System Status – Fuse Fail Reporting Code (Tens Digit)
345
System Status – Fuse Fail Reporting Code (Units Digit)
Table 91: System Status – Fuse Fail Report Locations
A system trouble report (Contact ID Event Code 300) will be transmitted when either the
codepad fuse or the accessories fuse has blown. A delay of approximately 10 seconds will be
between from when the fuse has blown and when the system will report the event.
System Status – Fuse Fail Restore Report
LOCATION 346 - 347
Location Description
346
System Status – Fuse Fail Restore Reporting Code (Tens Digit)
347
System Status – Fuse Fail Restore Reporting Code (Units Digit)
Table 92: System Status – Fuse Fail Restore Report Locations
A system trouble restore report (Contact ID Event Code 300) will be transmitted when either
the codepad fuse or the accessories fuse has been replaced. A delay of approximately 10
seconds will be between from when the fuse has been replaced and when the system will report
the event.
