136
Solution 862
Installation Manual
Transmission Format For Receiver 2
LOCATION 073
1
Enter the desired transmission format here. This location selects the data format that will be
transmitted to the base station receiver. This location also allows you to configure the control
panel for domestic or basic pager formats.
Option Transmission Format Option Transmission Format
1
Contact ID
4
Domestic
2
4 + 2 Express
5
Basic Pager
3
FSK (300 Baud) BELL
Table 57: Transmission Formats For Receiver 2
Subscriber ID Number For Receiver 2
LOCATION 074 – 079
000000
This number is transmitted to identify the calling control panel. Enter the desired Subscriber
ID Number in the six locations provided. For Basic Pager Format, “LOCATION 074 – 076”
will be ignored and the first digit of the Subscriber ID Number required must start in
“LOCATION 077”. When using Domestic Dialling Format, the number of identification
beeps will be the number that is programmed in “LOCATION 079”. This gives the ability to
identify between 15 different control panels calling the same telephone number.
Example
If you wish to program the Subscriber ID Number as 4729, you would program the six
locations as follows:
004729
ISSUE130 Electronics Design and Manufacturing Pty Limited
