178
Solution 862
Installation Manual
Zone Status – Sensor Watch Reports
LOCATION 329 - 330
45
Location Description
329
Sensor Watch Report
330
Sensor Watch Restore Report
Table 82: Zone Status – Sensor Watch Report Locations
A "Self Test Failure" report (Contact ID Event Code 307) will be transmitted to the base
station receiver when a zone has not been triggered during the Sensor Watch Time
programmed in "LOCATION 408 - 409" on page 206. This report will continue to be
transmitted (according to the frequency of the sensor watch time) until the fault has been
rectified.
To clear the fault and stop any further reporting, the zone that registered the fault must be
unsealed and resealed again. Refer to "LOCATION 408 - 409" on page 206 to set the number
of days a zone may remain sealed before registering as a fault. Refer to Zone Options 1 on
page 167 to program zones to be monitored by the sensor watch feature.
If "Self Test Failure" reports are not required, program "LOCATION 329 - 330" with a zero.
Zone Status – Alarm Restore Code
LOCATION 331
If you wish the control panel to transmit zone alarm restore reports, this location should be
programmed as 14. If you do not wish to transmit zone restore reports, this location should be
programmed as a zero.
“LOCATION 332” will be ignored when programming the alarm restore code and is global for
all zones. A zone restore report will only report to the receiving party that the zone has been
allocated to (e.g.: Receiver 1 or Receiver 2 etc).
Zone Status Reporting Options
LOCATION 332
Option Description
0
No Report Required
1
Receiver 1
2
Receiver 2
4
Receiver 1 and Receiver 2
8
Receiver 2 Only When Receiver 1 Fails
Table 83: Zone Status Reporting Options Location
This location is factory default to report only to receiver 1. You can select whether the zone
status reports will report on, receiver 1, receiver 2, both receiver 1 and receiver 2, receiver 2
only when receiver 1 fails or no reporting at all.
ISSUE130 Electronics Design and Manufacturing Pty Limited
