Dialler Information
This section outlines the programming information required for the
Solution 862
control
panel when communicating with base station receivers. Typically these parameters specify the
telephone numbers to call, the transmission formats, handshake tones and transmission speeds.
The control panel has the ability to report event information from two on-board diallers. he
first dialler reports to Receiver 1 and the second dialler reports to Receiver 2. Each dialler has
the ability to be programmed with two separate telephone numbers, handshake tone, reporting
format type and Subscriber ID Number.
Example
Dialler 1 could be set up to report in Domestic Dialling Format and reports to Receiver 1.
Dialler 2 could be set up to report to a base station receiver in Contact ID Format only when
Dialler 1 was unsuccessful.
How To Program A Telephone Number
When programming the telephone number, if a '0' is required, it must be programmed as a '10'.
Each location in the primary, secondary and call back telephone numbers hold one digit of the
telephone number.
To tell the dialler when the end of the telephone number has been reached, a '0' must be
inserted at the end of the telephone number. herefore the dialling sequence will be terminated
when a zero appears.
Example
To program the telephone number 9672 1055 as the Primary Telephone Number for Receiver
1, you would program the following:
LOCATION 000 - 015
96721 5500000000
.
Programming A Four Second Pause In The Telephone Number
To enter a four-second pause in the dialling sequence, you would need to program the value
'13'. This may be necessary when the dialler is communicating through an old (slower)
telephone exchange or where a PABX system is in place.
Example
To program the telephone number 02 pause 9672 1055 as the Primary Telephone Number for
Receiver 2, you would program the following:
LOCATION 040 - 055
2 96721 5500000
.
Digit Required Number To Program Digit Required Number To Program
0
10
8
8
1
1
9
9
2
2
End Of Number
0
3
3
*
11
4
4
#
12
5
5
4 Second Pause
13
6
6
Break
14
7
7
Table 53: Dialling Digits
130
Solution 862
Installation Manual
ISSUE130 Electronics Design and Manufacturing Pty Limited
