Solution 862
Installation Manual
Handshake Tone For Receiver 1
LOCATION 032
1
This location sets the type of handshake tone required for receiver 1 before data transmissions
to the monitoring station will begin.
1.
HI LO Handshake Tone is required when the control panel requires to communicate in
Contact ID Format or High Speed DTMF.
2.
1400 Hz Handshake Tone is required when the control panel requires to communicate
in Ademco Lo Speed Format or Domestic Dialling Format.
3.
Reserved.
4.
No Handshake Tone is not recommended.
5.
Pager Handshake Tone is required when the control panel needs to communicate in
Basic Pager Format.
Option Handshake Tone Option Handshake Tone
1
HI LO Handshake
(Contact ID Format)
4
No Handshake
2
1400 Hz Lo Speed
(Ademco Tx At 1900Hz)
5
Pager Handshake
3
2300 Hz (Low Speed Sescoa)
Table 54: Handshake Tones For Receiver 1
