144
Solution 862
Installation Manual
Programming Option Bits
When programming these locations, you will notice that there are four options per location.
You may select one, two, three or all four of these options, however, only one number needs to
be programmed. This number is calculated by adding the option bit numbers together.
Example
If at "LOCATION 177" you want options 1, 2 and 4, add the numbers together and the total is
the number to be programmed. In this example, the number to be programmed is 7 (i.e. 1 + 2
+ 4 = 7).
Option Description
1
Dialler Reporting Functions Allowed
2
Remote Arming Via The Telephone Allowed
4
Answering Machine Bypass Only When Armed
8
Use Bell 103 For FSK Format (Disabled = CCITT V21)
Table 63: Example - Programming Option Bits
ISSUE130 Electronics Design and Manufacturing Pty Limited
