28
Solution 862
Installation Manual
Programming Option Bits
When programming these locations, you will notice that there are four alternatives per location.
You may select one, two, three or all of these alternatives for each location, however, only one
number is required to be programmed. This number is calculated by adding the option bit
numbers together.
Example
If at "LOCATION 177" you want options 1, 2 and 4, add the numbers together and the total is
the number to be programmed. In this example, the number to be programmed is 7 (i.e. 1 + 2
+ 4 = 7).
Option Description
1
Enabled = Allow Dialler Reporting Functions
Disabled = Disable All Dialler Reporting Functions
2
Enable Remote Arming Via The Telephone
4
Enable Answering Machine Bypass Only When Armed
8
Enabled = Use Bell 103 For FSK Format
Disabled = CCITT V21 Format
Table 4: Example - Programming Option Bits
ISSUE130 Electronics Design and Manufacturing Pty Limited
