Fault Analysis Mode
Whenever a system fault occurs, the
FAULT
or
MAINS
indicator will flash and the codepad will
beep once every minute.
If the
MAINS
indicator is flashing, this is because the AC mains supply has been disconnected
from the control panel. If the AC mains supply has been disconnected continuously for more
than 2 minutes, the control panel will send an “AC Loss” signal (Contact ID Event Code 301)
to the base station receiver and the codepad will commence beeping once every minute until
the AC mains supply has been reconnected or acknowledged by pressing the
button.
When the AC mains supply has been restored, the
MAINS
indicator will automatically stop
flashing and return to its normal state. Once the AC mains supply has been connected
continuously for two minutes, the control panel will send an “AC Loss” restore report and the
codepad will automatically stop it’s once a minute beep.
How To Determine The Type Of System Fault
To determine all system faults other than the AC mains supply, enter fault analysis mode by
following the procedures below.
1.
Hold down the
5
button until two beeps are heard.
The
FAULT
indicator will remain steady and the
STAY
and
AWAY
indicators will flash
in unison with each other.
The illuminated
ZONE
indicators will indicate the type of system fault that has
occurred. Refer to "Table 20: Fault Indicators" below for the list of different system
faults that may occur.
2.
To exit fault analysis mode, press the
button. The
STAY
and
AWAY
indicators
will extinguish and the
FAULT
indicator will remain illuminated.
Zone Indicator Fault Description
1
Low Battery
2
Date and Time
3
Sensor Watch
4
Horn Speaker Disconnected
5
Telephone Line Fault
6
E
2
Fault
7
Fuse Fail
8
Communications Failure
Table 20: Fault Indicators
How To Acknowledge The System Fault
1.
To acknowledge the system fault, press the button. The
FAULT
indicator will
remain illuminated and the codepad will cease its once a minute beep.
